Burndy YA39N Terminal Lug 1-Hole Hylug Code Conductor Long Barrel Uninsulated Compression 1/2" 750 kcmil

Your Price: $37.50

QTY Available to Ship:

Quantity:

Ask a question

Fruit Ridge Tools is not an authorized distributor, reseller or representative of the products featured on this website. All product names, trademarks, brands and logos used on this site are the property of their respective owners. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to indicate any affiliation with or authorization by any rights holder.

Product Description

Burndy YA39N 1-hole terminal lug 750 kcmil AWG. Bulk packed loose with no individual packaging; as a result some may have minor dings. Features include:

No inspection window is ideal for more corrosive environments as the barrel transition is not open
Barrel is designed with an internal chamfer at the wire entry to ensure smooth insertion of the wire, preventing possible damaging of the wire strands during insertion
Long barrel allows for an increased number of crimps which will increase the mechanical strength of the connection
NO inspection window
Electro-tin plated unless otherwise specified to reduce galvanic corrosion (bimetallic) and resist corrosive elements
Connectors are clearly marked with stamping and barrel color coding
UL Listed 90-Degree C, Up to 35 kV
Stud Hole Size: 1/2
Tongue Width: 1.91
Tongue Thickness: .27
Barrel Length: 2.88
Overall Length: 5.11
Die Index 24
Electrolytic Tin Plated Seamless Copper

MPN:

YA39N

Cross Reference:

Not Available

Color:

Silver

Condition:

New

UPC:

DOES NOT APPLY

Weight:

0.80 LBS

Most orders ship same day if received by 2:00 pm EST Mon-Fri and 12:00 pm EST Sat. Some larger orders or items that require special handling may be shipped next business day.
