- New Leviton Blue 16 Series Vulcanized Cam-Type Plug 400A 600V Crimped 16V23-B
QTY Available to Ship:
13
Fruit Ridge Tools is not an authorized distributor, reseller or representative of the products featured on this website. All product names, trademarks, brands and logos used on this site are the property of their respective owners. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to indicate any affiliation with or authorization by any rights holder.
)
Product Description
This is a Leviton #16V23-B blue male vulcanized cam-type plug - crimped. These are for use with 16 Series taper nose connectors. Features include:
- Rated up to 400A 600V (with proper cabling)
- Cable capacity: 1/0 to 2/0 AWG
- Intermateable and completely compatible with competitive cam-type products - can be retrofitted to existing locations and power distribution systems
- Locking and reinforcing ring won't melt, break or crack
- Shatter and crack proof - high durometer thermoplastic elastomer(TPE) or neoprene rubber
- Color coded insulating sleeves - fast and easy phase identification
- Prevents arcing or burning - no movement of contact surfaces
- Self compensating for wear - slit and cam in male contact provides spring action for longer usage
- Quick connect/disconnect - twist and pull provided by double cam male and cam button in female
- High conductivity - positive vibration-proof connection provided by double cam design
MPN:
16V23-B
Cross Reference:
Not Available
Color:
Blue
Amperage:
400A
Condition:
New
UPC:
078477989548
Weight:
1.00 LBS
