Eaton Main Lug Circuit Breaker Panel 2-Space 4-Circuit 120/240V 40A CH2L40SP

Your Price: $69.99

QTY Available to Ship:

Quantity:

Ask a question

Fruit Ridge Tools is not an authorized distributor, reseller or representative of the products featured on this website. All product names, trademarks, brands and logos used on this site are the property of their respective owners. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to indicate any affiliation with or authorization by any rights holder.

Product Description

Eaton CH2L40SP main lug loadcenter. Features include:

40A Amp indoor main lug loadcenter: single phase, 4-pole, 3-wire, 120/240V single phase
Suitable for use as service equipment when not more than two service disconnecting mains are provided or when not used as a lighting and appliance panelboard.
Ground bar kit sold separately: use Type GBK5 or GBK520 ground bar
Copper bus
Wire size: #14-6 AWG
Feed: top/bottom
Box size:5
Dimensions: 9.44"h x 4.5"w x 3.0"d
2 spaces (up to 4 circuits)
Uses CHT type breakers
Surface mount
Removable cover is included

MPN:

CH2L40FP/CH2L40SP

Cross Reference:

Not Available

Color:

N/A

Amperage:

40A

Condition:

New

UPC:

N.A.

Weight:

3.60 LBS

Most orders ship same day if received by 2:00 pm EST Mon-Fri and 12:00 pm EST Sat. Some larger orders or items that require special handling may be shipped next business day.
