Hubbell Corrosion Resistant Locking Flanged Receptacle Outlet NEMA L15-20R 20A 250V 3 Phase HBL24CM26

Your Price: $24.99
SKU:
HUBHBL24CM26-EA

*Same Day Shipping

QTY Available to Ship:
35

Fruit Ridge Tools is not an authorized distributor, reseller or representative of the products featured on this website. All product names, trademarks, brands and logos used on this site are the property of their respective owners. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to indicate any affiliation with or authorization by any rights holder.


Product Description

Hubbell HBL24CM26 yellow corrosion resistant locking flanged outlet. Industrial Specification Grade, NEMA L15-20R, 3-pole, 4-wire, grounding, rated 20A 250V 3-Phase delta. Terminals accommodate #16-#8 AWG. Each is individually packaged; packaging may differ from photo. Features include:
  • One-piece, rivetless, brass contacts offer enlarged contact surface area, low heat, and long life
  • Internal wiring chambers isolate individual conductors to prevent flashover, arcing, and stray strands of wire
  • Deep-funnelled, large rectangular-shaped chamfered wire wells guide conductors into termination position
  • Transparent wiring chambers provide a means of visual inspection of conductors and terminals
  • Wire clamps move within individual chambers to provide positive crimp lock without cutting wire strands
  • Color-coded terminal screws
  • Molded-in strip gage provides correct measurement for proper strip length of conductor
  • Captive terminal screws eliminate nuisance dropping and searching for missing screws
  • Positive crimp contact plate bundles stranded wire maximizing wire/clamp surface contact
  • Combination #10-32 deep slotted/ Phillips brass screws
  • Super tough nylon body resists damage from severe impact, abrasion, and chemical attack
  • NEMA configuration, agency certifications, and device rating are printed on front of device to assist with identification

MPN:
HBL24CM26
Cross Reference:
Not Available
Color:
N/A
Amperage:
20A

Condition:
New
UPC:
783585358482
Weight:
0.15 LBS
Most orders ship same day if received by 2:00 pm EST Mon-Fri and 12:00 pm EST Sat. Some larger orders or items that require special handling may be shipped next business day.
$4.95 Flat Rate Shipping
