Bryant Watertight Pin & Sleeve Connector Female Plug 32A 100-130V 2P3W 332C4W

Your Price: $69.99
QTY Available to Ship:
7

Fruit Ridge Tools is not an authorized distributor, reseller or representative of the products featured on this website. All product names, trademarks, brands and logos used on this site are the property of their respective owners. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to indicate any affiliation with or authorization by any rights holder.


Product Description

Bryant 332C4W watertight pin and sleeve connector (Bryant is a division of Hubbell). Manufactured for International Power Ratings (European); as a result they are not UL Listed or CSA Certified. Industrial Grade, IEC 309, 2-pole, 3-wire, grounding, rated 32A 100-130V. Each is individually packaged; packaging may differ from photo. Features include:
  • External housing key on male devices mates with keyway on female devices to provide proper alignment and simplify the connection of devices. Keyway is always located at the 6 o’clock position and is clearly visible to the user, helping to prevent the mismating of devices with different ratings
  • Spring-loaded gasketed cover
  • Self-adjusting contacts provide accurate pin insertion, producing self-cleaning effect as pin is inserted and withdrawn from sleeve
  • High temperature contact carrier
  • Radial rib exterior
  • Phase contacts are recessed in deep insulated chambers to minimize arcing
  • Ground contact in forward position ensures first make, last break, neutral contact connects next, then phase contacts
  • Terminal screws are backed out for easy assembly

MPN:
332C4W
Cross Reference:
Not Available
Color:
N/A
Amperage:
32A

Condition:
New
UPC:
781786250512
Weight:
0.85 LBS
